THP2140 Pressure Control

Components & Other Products
THP2140 Pressure Control
THP2140 Pressure Control

Description

- Pressure Control For Air-Conditioners.

ADD INQUIRY

Specifications

Model/ItemOperating Pressure (Kgf/c㎡) Range (Kgf/c㎡) Contact Style Max Operating Pressure (Kgf/c㎡) Max Bellow Pressure (Kgf/c㎡) Max Allowable Temp. (℃) Capillary Tube Length (mm) Inquiry
ON OFF EIFF MIN. MAX.
THP2140 Pressure Control 17.0±1.5 21.0-0 21.0-1.5 4 17 30 S.P.D.T. 33 16.5 70 1000
